QDX
INERGY
84137099
OPERATING CONDITIONS
l Ambient temperature type: ≤40℃
l Liquid temperature range: 60℃
l Total suction lift up to 9m
l Continuous duty
PUMP
l Pump Body: Anti-UV Plastic
l Impeller: Nylon Plastic
l Mechanical Seal: Carbon / Ceramic / Stainless Steel
l Float Switch: With/Without
MOTOR
l Single Phase
l Heavy Duty Continuous Work
l Motor Housing: Aluminum / Cast Iron
l Shaft: Carbon Steel / Stainless Steel
l Insulation: Class B / Class F
l Protection: IP68
l Water Cooling
OPERATING CONDITIONS
l Ambient temperature type: ≤40℃
l Liquid temperature range: 60℃
l Total suction lift up to 9m
l Continuous duty
PUMP
l Pump Body: Anti-UV Plastic
l Impeller: Nylon Plastic
l Mechanical Seal: Carbon / Ceramic / Stainless Steel
l Float Switch: With/Without
MOTOR
l Single Phase
l Heavy Duty Continuous Work
l Motor Housing: Aluminum / Cast Iron
l Shaft: Carbon Steel / Stainless Steel
l Insulation: Class B / Class F
l Protection: IP68
l Water Cooling
