JST
OEM
84137099
OPERATING CONDITIONS
l Liquid temperature up to 60℃
l Ambient temperature up to 40℃
l Total Suction lift up to 9m
l Continuous duty
PUMP
l Pump Body:Stainless Steel
l Impeller:Stainless Steel
l Mechanical Seal: Ceramic graphite and rubber
MOTOR
l Bulit-in thermal protector for the single phase motor
l Insulation: Class B / Class F
l Protection: IP44/IP54
OPERATING CONDITIONS
l Liquid temperature up to 60℃
l Ambient temperature up to 40℃
l Total Suction lift up to 9m
l Continuous duty
PUMP
l Pump Body:Stainless Steel
l Impeller:Stainless Steel
l Mechanical Seal: Ceramic graphite and rubber
MOTOR
l Bulit-in thermal protector for the single phase motor
l Insulation: Class B / Class F
l Protection: IP44/IP54
