YDLQ
INERGY
84137099
OPERATING CONDITIONS
l Liquid temperature up to 60℃
l Ambient temperature up to 40℃
l Total Suction lift up to 9m
l Continuous duty
l PH: 6.5 to 8.5
PUMP
l Pump Body: Cast Iron
l Impeller: Brass
l Mechanical Seal: Carbon / Ceramic / Stainless Steel
MOTOR
l Single Phase
l Heavy Duty Continuous Work
l Motor Housing: Aluminum Shaft: AISI304
l Insulation: Class B / Class F Protection: IPX4
l Cooling: External Ventilation
ADVANTAGES & FEATURES
l Small size,,high pressure
l Easy installation & maintenance
OPERATING CONDITIONS
l Liquid temperature up to 60℃
l Ambient temperature up to 40℃
l Total Suction lift up to 9m
l Continuous duty
l PH: 6.5 to 8.5
PUMP
l Pump Body: Cast Iron
l Impeller: Brass
l Mechanical Seal: Carbon / Ceramic / Stainless Steel
MOTOR
l Single Phase
l Heavy Duty Continuous Work
l Motor Housing: Aluminum Shaft: AISI304
l Insulation: Class B / Class F Protection: IPX4
l Cooling: External Ventilation
ADVANTAGES & FEATURES
l Small size,,high pressure
l Easy installation & maintenance
